Small Footprint Big on Power

Bigger Size. Bigger Earnings.

The Maxima Z is a superior 3W which offers best-in-class performance, durability & comfort. With its bigger size, the riders can enjoy greater earnings than normal 3Ws

Performance at a Glance

0nm

MAX TORQUE

0KW

ENGINE OUTPUT

0cc

ENGINE CAPACITY

0L

FUEL TANK

0kgs

KERB WEIGHT

Click and Drag for 360 View

  • CHOOSE YOUR COLOUR:
  • Black
  • Black Yellow
  • Blue
  • Green
  • Red
  • White
  • Yellow

WHAT POWERS THE BAJAJ Maxima Z PETROL

WHAT-POWERS-THE-1st-Scroll-MAXIMUM-Engine-RE-Maxima-Z

MAXIMUM Engine

Maximize earnings with a 236cc DTS-i engine that produces 8.19kW and torque of 20.45Nm to power extra trips with full cargo or passenger payloads.

Twin Sparked 4 Stroke Engine

Cv shaft

Go maintenance-free for up to 100,000 kms with a high-tech CV shaft that endures heavy duty performance.

re4s tecg

Long-lasting Dry Clutch with Car-type CV Shaft

A long lasting dry clutch, and CV shaft with zero-maintenance for 1,00,000 kms means you keep driving uninterrupted by breakdowns for much longer. .

re4s tecg

5-Speed Gearbox with Car-type Clutch Pedal

Conquer even challenging roadways usually found outside city limits with a 5-speed gearbox that improves driveability and fuel efficiency. A car-type clutch pedal also makes driving more effort-free.

THE COMPLETE SPECIFICATIONS

Engine

  • Type: Four Stroke, Air & Oil cooled, Twin Spark plug, S. I. Engine
  • Max Power: 8.19 KW @ 4500 rpm
  • Max Torque: 20.45 Nm @ 3500 rpm
  • Displacement: 236.2 cc
  • Max Speed:60 km/h
  • Clutch:Wet, Multiplate

Brakes & Tyres

  • Break Size Front: Hydraulic Expanding Friction Shoe Type with TMC – Foot operated
  • Brake Size Rear: Hydraulic Expanding Friction Shoe Type with TMC – Foot operated
  • Tyre Front: 4.00 - 10, 6 P.R.
  • Tyre Rear: 4.00 - 10, 6 P.R.
  • Brake Type Front: Hydraulically actuated brake shoes – Leading & Trailing Type

VEHICLE

  • Wheel Base: 2000 mm
  • Frame Type: Monocoque chassis with central beam and cross member welded
  • Length x Width x Height: 2825 mm x 1350 mm x 1780 mm
  • Ground Clearance: 200 mm
  • Suspension Front: Fork with Leading Arm and Anti-dive link, twin Hydraulic shock absorbers and Helical springs
  • Kerb Weight: 420 Kgs
  • Fuel Tank (Reserve / Usable): 8 L
  • Suspension Rear: Independently sprung rear wheels by trailing arms with helical springs and hydraulic shock absorbers

ELECTRICALS

  • System: 12V DC
  • Battery: 12V 32AH
  • Tail Lamps: 12V 21/5W
  • Reverse Lamp: 12 V 10W
  • Head Lamps: 12V35/35W (HS1)
